Quenched and tempered cast steel range with mechanical values (Charpy-V > 42 Joule /-20°C) for tough and low temperature use. For wire rope diameter 6 - 203 mm (1/4” - 8”).
- Pin securing by cotter pin or bolt securing by nut and cotter pin.
- Optional is a flange connection for use with a bend stiffener.
- All spelter sockets have a 100% efficiency.
- Material: Quenched and tempered cast steel
- Marking: Size, wire rope diameter and batch or serial number.
- Finish: Blue painted
- Note: For intermediate rope diameter select fittings with nearest following size.
- Warning: Compare the spelter's and the wire rope's minimum breaking load.
